10000 VA/10000 W UPS, Online Double Conversion, 200 - 240 Vac Input, 120 - 240 Vac Output, Hardwired Input, Pure Sine Wave, 8 UR Tower or Rack, With 6 NEMA 5-20R Outlets, 3 NEMA L6-30R and Hardwire Terminal

*Note: This equipment must be started by a CyberPower expert to make the warranty effective. For more information contact the Engineering department.

To carry out the start-up of the equipment, it must be ready on the scheduled date with the following characteristics:

• 6 AWG cable from the wiring to the UPS.
• Suitable supply voltage level of 200-240 VAC.
• 60 Amp input switch (2x30).
• Isolated landing system well referenced to ground.

Applications:

Ensures power backup protection for IT equipment, servers, workstations, NAS / storage devices, telecommunications devices, network devices, security/emergency systems and surveillance systems. The UPS adopts a double conversion topology to provide high-quality output power with additional ECO Mode to save energy and save on energy costs. This generator-compatible UPS includes hot-swappable battery packs for maintenance without power interruption and a switch. Emergency Power Off (EPO) feature to allow users to shut down the UPS immediately during an emergency.

Technical specifications:

• Input voltage: 200 - 240 Vac
• Input frequency: 40 - 70 Hz
• Power Factor: 1
• Hardwired Input Plug Type: Heavy Duty Cable
• Cable length: N/A
• VA output: 10,000
• Output Watts: 10,000
• Batteries: 20 x 12V/9Ah
• Backup time with full load (10,000 W): 3.6 Minutes
• Backup time with half load (5000 W): 10 Minutes
• Battery Voltage: 120 Vac; 200, 208, 220, 230, 240 Vac (Configurable) ±2%.
• Total output sockets: 10
• Socket type: NEMA 5-20R (6) NEMA L6-30R (3), Hardwired Terminal Block (1)
• Surge protection: network grade.
• Remote SNMP/HTTP Management: RMCARD205 (Optional)
• Extended Battery Module: BP240VL3U01
• Indicators: LCD readout screen
• Rack Size: 8 UR
• Dimensions: 433 x 352 x 660 mm (Width x Height x Depth)
• Weight: 157.4kg
• 3 years warranty (battery included)
