Tap -10 dB separator with frequency range from 575 to 6000 MHz. Ideal to separate the antennas at different coaxial cable lengths. 50 OHM with female n connectors.

  • e4871daab2aa5380185fc53cb68db26f
  • e4871daab2aa5380185fc53cb68db26f
1 2
  • Ideal for when you want to cover a small and large area with the same amplifier.
  • With female n connectors.
  • 50 ohm impedance.
  • Separator with output of -10 dB and -1.1 db

11 in stock

Modelo: 859-120

Proveedor: WILSONPRO / WEBOOST

Código SAT: 32101500

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Tap -10 dB separator with frequency range from 575 to 6000 MHz. 50 OHM with female N connectors.

For use in signal distribution systems to divide the amplified signal for multiple internal antennas for a minimum signal loss or to control the amount of signal in small and large areas. It presents a low loss signal with a derivation of -10 dB.

It provides outputs with different levels to compensate for the differences in loss in the lengths of the cables & Comma; and so that the nível that reaches the antennas is uniform.

Loss: -10 db / -1.1 db

Divided relationship: 90% / 10%



Specs

Model 859-907
Connectors N female
Dimensions 178 x 79 x 32 mm
Frequency range 575-6000 MHz
Impedance 50 ohm
Weight 0.41 kg

Loss: 10 dB in separation and 1.1 dB passing
