EdgeMAX Managed 8-Port Gigabit Switch with PoE+/Passive PoE 24V + 2 SFP Ports, 150 W

  • 6f7e38b36323e70cfa93883c254cff7e
  • a03a8694e6288a114e0262a90d783c40
  • 4cf2768a677afb08a490607681a0dc6e
  • c5239c572ca890ea02e2102c4c2b5d43
1 4
  • 8 puertos 10/100/1000 Mbps, 2 puertos SFP gigabit
  • Forwarding rate de 14.88 millones de paquetes/segundo
  • POE IEEE 802.3af/at, potencia total de 150 W
  • Soporte ruteo estático con hasta 16 rutas configurables
  • Administración avanzada: Web UI, CLI, SNMP, SSH

Out of stock

Modelo: ES-8-150W

Proveedor: UBIQUITI NETWORKS

Código SAT: 43222600

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Ports:

8 10/100/1000 Mbps ports.

2 Gigabit SFP ports.

Forwarding rate: 14.88 Million packets per second (Mpps).

Switch Fabric: 20 Gbps.

PoE:

IEEE 802.3af Power Over Ethernet (PoE).

IEEE 802.3at Power Over Ethernet plus (PoE+).

Passive 24V.

Total power: 150W.


Administration:

Graphical user interface (Web UI).

Command Line Interface (CLI).

SNMP v1, v2 and v3.

SSH.

Telnet.

Specifications:

MAC Addresses: 16:384.

MSTP instances: 4.

LAGSs: 6.

ACL's: 100 with 10 rules per port.

Queues: 8.

Layer 2 Features:

DHCP Snooping.

IGMP Snooping.

Port Mirroring.

TACACS+.

Layer 3 Features:

Static routing: Up to 16 routes.


Physical and electrical characteristics:

AC power: 100-240 VAC, 50-60Hz.

DC power: 46-56 VDC.

Dimensions: 1 U Rack, 43 x 204 x 235mm.

Weight: 1.8kg.

Operating Temperature: -25 to 45° C.

Includes:

Wall mounting, brackets and screws.

Power cord.


Warranty:

1 year.

Business class features.

EdgeSwitch® supports a broad set of Layer 2 features and protocols and also provides Layer 3 static routing capability.

Advanced user interface.

The complete user interface is easy to learn and allows configuration and monitoring in a Web interface.
