Physical Characteristics

Dimensions

198 x 70 x 81.20mm

Protection against water and dust

IP54

Fall test

1.5m

Operating Temperature

-20C to +60C

Screen and Buttons

Diagonal measurement

5"

Resolution

HD 720*1280

Pixels per inch (PPI)

293

Guy

IPS

Characteristics

Anti Glare Screen

Capacitive 5 points

Operation in wet conditions

Glove operation

Buttons and Keys

Power button

PTT

Emergency button

audio potentiometer

Buttons P1-P4

LED power indicator

Indicator LEDs on top

Hardware

Processor

Quad-core MTK 1.5GHz, 64 bit

Memory

2GB RAM

16GB ROM Expandable up to 128GB with Micro SD card

Battery

Removable, 4000 mAh Lithium Polymers

Sensors

Accelerometer, Proximity and Geomagnetic

Connectivity

Cellular Networks

GSM: B2/3/5

WCDMA: B1/B2/B4/B5

TFDD-LTE: B2/B4/B5/B7/B12/B13/B17/B28a/B28b/B66

TDD-LTE: B41

WLAN

WiFi IEEE 802.11 b/g/n/ 2.4/5GHz

Bluetooth

V4.0 LE

Location

GPS, GLONASS, BEIDOU and QZSS

Interface

Dual SIM Micro

Micro SD slot

Type C USB 2.0

10-pin connector for handheld microphone, desktop, PTT pedal, etc

3.5mm connector with support for external speaker and hands-free.

3 pin power connector

Connectors for external antennas

Platform

OS

Android 8.1

Preloaded apps

TASSTA PTT

Audio

Dual microphone

Windproof Noise Canceling Dual Microphone

Horn

5 Watts Radio Quality

Accessories

Included

Screws and mounting

Power cord

handheld microphone

Antennas

Quick User Guide

Optionals not included

desktop microphone

Pedal PTT

15 Watt external speaker
