airMAX AC GEN2 Base Station Radio up to 500 Mbps, 5 GHz (5150 - 5875 MHz) with airPrism technology

  • 70753b4a1be237e03cff48aeabcef262
  • 1151c3581e283f8399ca440cc475b4d2
  • bb2403457c8042c119991e47ab1283da
  • b8d94c87e5e33c885de90831b6a99ef3
1 4
  • Puerto de datos 10/100/1000 Mbps para alta velocidad
  • Anchos de canal ajustable hasta 80 MHz
  • Rango operativo 5150 - 5875 MHz según país
  • Alimentación 24 VDC, adaptador PoE gigabit incluido
  • Alta seguridad con cifrado WPA2 AES

200 in stock

Modelo: RP-5AC-GEN2

Proveedor: UBIQUITI NETWORKS

Código SAT: 43222640

Tax included.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Ports:

1 10/100/1000 Mbps data port.

RF Connectors:

2 x RP-SMA, 1 x GPS.

OS:

airOS® 8.

Modes of Operation:

Access Point.

Season.
*Performance values ​​and the number of clients may vary depending on the environmental and installation conditions of the CPE clients.

Characteristics:

Adjustable channel widths:

  • PtP: 10/20/30/40/50/60/80 MHz.
  • PtMP: 10/20/30/40 MHz.

2 Reverse SMA Female connectors for connecting external antennas (not included).

Operating range (5150 - 5875 MHz) depends on country.

Atheros MIPS processor.

Strong WPA2 AES security.

High performance.

Administration radio in 2.4 GHz.

Improved SNR.

Improved noise immunity.
Physical and Electrical Characteristics:

Power: 24 VDC, 1 A. Gigabit PoE Adapter.

Dimensions: 88 x 230 x 40 mm.

Weight: 400g.

Operating Temperature: -40 to 80° C.

Includes:

Gigabit PoE Adapter 24 VDC 1 A.

Warranty:

1 year.

Management Wi-Fi radio.

The Rocket® Prism AC integrates a separate Wi-Fi radio for quick and easy setup using a mobile device.

Improved download protection.

The Rocket® Prism AC offers enhanced protection against ESD events.

Revolutionary technology.

Ubiquiti's patented airPrism technology provides selective radio and advanced performance, which isolates signals within the operational channel to increase capacity and performance in co-location deployments.

Designed for high performance.

The Rocket® Prism AC features a metal casing with EMI protection, GPS, airPrism circuitry and airView® real-time spectrum analysis to deliver the best efficiency and performance.

Full band coverage at 2.4 and 5 GHz.

The Rocket® Prism 5AC offers complete coverage of the 5 GHz spectrum with a single radio, and the 2.4 GHz band is covered by the Rocket® Prism 2AC.


GPS synchronization

AirPrism Active RF Filter

Model Comparison

M5
M5
R5AC-Lite
R5AC-Lite
RP‑5AC‑Gen2
RP‑5AC‑Gen2
Frequency 5GHz Full-Band 5 GHz Full-Band 5 GHz
Throughput 150+Mbps 500+ Mbps (Max. 80 MHz) 500+ Mbps (Max. 80 MHz)
Ports (1) 10/100 Ethernet (1) 10/100/1000 Ethernet (1) 10/100/1000 Ethernet Port
airPrism™ Technology ✔
Management Radio ✔
GPS Sync ✔
