PoE Lightning Protector Ideal for Gigabit Wireless Links and IP Cameras with Gas Surge Tube Technology

  • d63c134132b6cb3b688b19abf8749784
  • 829406fff3408672ce349c6fe460d021
  • 9504d98e02c09a3185c8dcdd1334b9b4
1 3
  • Gas tube technology (GDT)
  • Super fast response time in nanoseconds.
  • Compatible with CAT5, CAT5e and CAT6 cable
  • Gigabit Ethernet data rate.
  • Pole or wall mounting

59 in stock

Modelo: ALPU-L130

Proveedor: TRANSTECTOR

Código SAT: 39121634

Tax included.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

This Gigabit Ethernet/PoE+ SPD Transtector uses a shielded RJ45 for connection. Our industrial PoE lightning and surge protection for power surge suppression is part of the ALPU series. PoE Surge Protector PDF data sheet specifications and drawings with dimension details for ALPU-L130 are available for download above.

The surge protection for Gigabit Ethernet/PoE+ devices in this Transtector SPD component is in the form of a gas discharge tube (GDT). This TVSS data line uses gas discharge tube (GDT) circuits to protect electronic devices from spikes. Lightning transient surge suppression and strong electrical spike events for PoE are handled through GDT protection circuitry in the data line SPD. The ALPU-L130 Gigabit Ethernet/PoE+ commercial surge protection device is EN/IEC 60950-1 and UL 497B

Main features:
  • Gigabit ports.
  • Protection up to PoE+ (51W).
  • Protection modes:LG/ SG.
  • Impedance: 100Ω
  • Technology: Tube Gas Discharge (TGD).
  • Maximum current 1.5 A.
  • Suppression response time < 75 ns.
  • Temperature range: -40° to 65°C.
  • 1 year warranty.
Benefits:
  • Easy installation.
  • Protected pins (1&comma;2)&comma; (3&comma;6)&comma; (4&comma;5)&comma; (7&comma;8).
  • Exterior Protection. IP23
  • Weight: 150g.
  • Pole or wall mounting.
  • Shielded RJ45.
  • Compatible Cat5/5e UTP/STP&comma; Cat6/6A. STP
Applications:
  • Wireless links.
  • IP video surveillance.
  • Outdoor WiFi.
  • Data centers.

Note* The protector must be grounded

Typical surge protector installation scenario
