SecurOS UVSS Under-Vehicle Scanning FHD IP Vision Platform

  • 96acdb408088cc6f17d059b384f9baa6
  • 4262fc2194d7bbcac8a3d6919341d5eb
1 2
  • Requiere módulo de licencia UVSS modelo ISS-UVSS-S
  • Densidad de pixel 9 píxeles/cm
  • Distancia mínima del piso más 150 mm
  • Velocidad máxima del vehículo 15 Km/h
  • Tiempo de procesamiento de imagen 3 segundos
  • Calificación IP: IP68 que le otorga una alta resistencia al agua y polvo.

Out of stock

Modelo: ISS-UVSSH

Proveedor: ISS

Código SAT: 46171610

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

ISSUVSSH

ISS

SecurOS UVSS is a software-hardware based remote under-vehicle surveillance system. The system creates a database of high-resolution undercarriage images and vehicle license plate retrieval.

General characteristics

  • Built-in white LED lighting
  • Water resistant protection grade
  • Operating temperature -40º-60º C
  • Power supply 24Vdc/50W
  • Dimensions 970mm x 310mm x 196mm
  • Dimensions of the camera protective body (d. 86 mm, h. 146 mm)
  • UVSS Platform Weight of 12Kg
  • Semi-concealed mounting configuration installation (drilling in floor only for camera protective body)
  • Maximum distance between the UVSS platform and the controller 40 m.

Software

  • SecurOS VMS provides video surveillance, video recording and software - hardware system administration.
  • The SecurOS UVSS module provides undercarriage images under the vehicle for visual inspection and automatically detects foreign and/or undeclared objects.
  • SecurOS AUTO provides license plate recognition, advanced search and watchlist capabilities, etc
  • Embedded APIs offer interoperability with third-party devices and systems

    Advantages

    • The compact UVSS platform does not require time-consuming installation, and it is easy to maintain.
    • Use of video analysis detectors without the need for physical devices to detect the presence of the vehicle.
    • Automatic comparison of the undercarriage image with the reference image.
    • The maximum vehicle speed is up to 10 mph (15 km/h).
    • Interoperability with a surveillance camera(s), access control system, barriers, traffic lights, motion control devices, visual electronic display boards and more.

    Basic hardware UVSS platform

    • IP68 scanning system with Full HD IP camera and fisheye lens: mounted on the rail.
    • UVSS Controller. Processing server with data storage and integrated video management platform-SecurOS.
    • LPR/ANPR IP camera.
    • Operator's workstation.
