(MOTORIZED, NON-CONTACT), Industrial Stainless Steel Turnstile, Bidirectional, Rough Use, Space for Proximity Reader

  • 684f520cfffaab267816d4cac7dc4b45
  • 4925b2f040b58f1dbd8adb733a73a8e9
  • abe134fcc148a08e5a2b33cc5510134b
  • 5dde4df467247296ee57b9cfdf88a96e
  • 037219fc2e755b04a70be77ed013cfc2
  • 394257bd3989f59c533e222810539fb1
  • 174ea87515366ccf26f051c6b46d693b
1 7
  • 5,000,000 cycles guaranteed
  • Made of stainless steel
  • Motorized Rotor

Out of stock

Modelo: AP1000HDM

Proveedor: ACCESSPRO

Código SAT: 30171509

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

AP1000HDM

The turnstiles of the AccessPRO series are an efficient barrier type & comma; with a compact design & comma; and offer enough space to integrate any access control system. They can be installed with different accessories such as & comma; people counters & comma; card readers & comma; alarm systems against unauthorized access. Thanks to its arm abatement function, it provides an excellent solution in case of an emergency or loss of energy & comma; thus providing free exit in case of an evacuation. Excellent durability with minimal maintenance translates to years and millions of cycles without any problems. The AP1000HDM turnstile creates a safe environment for applications for example: receptions & comma; stadiums & comma; interior security and perimeter & comma; recreational parks etc...

Main features:
  • Dimensions: 480x280x960mm
  • Material: 1.0mm 304 SUS Hairline #400
  • Ancho de pasaje: ≦550mm
  • Flow of people: 30-35 per minute
  • Operation time: 0.2 Seconds
  • For indoor outdoor use.
Physical and Electrical Characteristics:
  • Input voltage: 100-240Vac. 50/60Hz
  • Operation voltage: 24Vdc
  • Communication interface: RS-485
  • Dry contact activation
Operation modes:
  • Access in one direction only.
  • Bi-directional entrance.

Featured Features:
  • Use RFID smart cards & comma; identity cards & comma; barcode readers or Qr code.
  • The direction indicator shows the pedestrian the status of the current reading and guides the pedestrian correctly.
  • Mechanical Mode: The pedestrian pushes the arm until it returns again to the starting position.
  • Unidirectional or bidirectional & comma; configurable on the turnstile.
  • AutoLock after each access.
  • Adjustable time delay.

  • Note: Does not include relay for counter.

  • Equipment for outdoor use under roof (protected from water and elements).
  • Requires maintenance of cleaning and protection with WD40 according to the installation area

Guarantee

AccessPRO HD series turnstiles with their improved rotor can guarantee up to 5 & comma;000 & comma;000 cycles before the first failure of the mechanism.

This is how we test our turnstiles to guarantee up to 5 & comma;000 & comma;000 of cycles without failure in mechanism.

2 years warranty.
