Mounting for Solar Panel, 5400mm \"8\" Rail for Modules with Thickness of 30-35mm, Max. Wind Speed. 136km/h (20° to 45°) With Black Anodizing

  • 8ae82bea76bb8593b3bcf49907265441
  • a98fa5ef50dc39bc437d15a0325d87e4
1 2

Out of stock

Modelo: VEKTOR8BLK

Proveedor: EPCOM POWERLINE

Código SAT: 60104701

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Anodized aluminum mounts, High resistance to wind and corrosion with a 25-year warranty.

Benefits of using EPCOM POWER LINE Anodized Aluminum mounts:

  • Mitigate corrosion due to the effect of "Galvanic Pair", Guarantee your installations against premature corrosion.
  • Wind resistance up to 136 km/h, ideal for areas with strong winds.
  • Easy installation and adaptability to your needs due to the wide variety of accessories available.
  • 25 year warranty against manufacturing defects!
  • Integrated "Ground Clip" landing system (does not include electrode or landing cable).

Aluminum mounting for concrete ceiling or floor, 1x4 photovoltaic module arrangement.

Main Features:

  • For arrangement of 1x4 photovoltaic modules of 35mm thickness
  • Tilt: 20-45°
  • Weight: 21.3kg
  • Max wind speed: 136 km/h

Special considerations:

For the installation of 4 modules, the width of each module must be less than 1134 mm.

*It is suggested to check compatibility with the engineering department.

Compatible modules:

- ET-M772BH550WW/WB (4 modules)

- EGE-550W-144M (M10) (4 modules)

- LP210*210M66MH665W (4 modules)

Epcom Power Line vs Competition

Advantages of Epcom Power Line Mounting Systems

  • Highest quality materials.
  • Quick and easy installation.
  • "Ground Clip" landing system for easy installation.
  • More robust pieces resistant to extreme climates.
  • Technical support 365 days a year.
  • 25 years warranty.
