HUAWEI eKit - Business Router / 2 ports 10/100/1000 Mbps combo 2 SFP port (WAN) / 8 port 10/100/1000 Mbps (WAN/LAN) / Performance 4 Gbps / VPN / Load Balancing / Up to 700 Clients / Free Cloud Administration

  • d8eb9be1c9256400d8224d6af03d4e3b
  • 807bd59fab4421dd6ccf8d50a972993f
  • 78d423dd4c59f93b76f386a526e4f8c7
  • 7a8d5a025728793755678470fcd0a9b4
1 4
  • Manage and configure your projects from the App - HUAWEI eKit - Totally Free.
  • Supports up to 700 clients.
  • Integrated firewall, IPS, URL filtering and multiple VPN technologies, providing comprehensive security protection capabilities
  • High-performance multi-core processor, supporting high-speed WAN connections, providing powerful path computing capabilities and improving L4-L7 service processing efficiency

11 in stock

Modelo: AR720

Proveedor: HUAWEI eKIT

Código SAT: 43222600

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details
Huawei NetEngine AR700 series routers are next-generation high-performance routers. They use ARM-based multicore processors and a non-blocking switching architecture, providing double the industry average performance. Also, They integrate various functions such as 5G, routing, switching, VPN, security and MPLS, enabling diversified business services in the cloud era.

General characteristics

  • Administration via web browser (Stand Alone), eKit App or eKit Cloud.
  • Free Cloud, free of licenses.
  • Load balancing.
  • Supports up to 700 clients.
  • VPN: IPSec VPN, GRE VPN, DSVPN, A2A VPN, L2TP VPN, and L2TPv3 VPN
  • Forwarding rate: 9 Mpps to 25 Mpps.
  • Ports: 2 x 10/100/1000BASE-T port combo 2 x GE SFP (WAN) + 8 x 10/100/1000BASE-T port (WAN/LAN).
  • 3 years warranty.
  • It works as an EkitEngine AP controller.
  • Load Balancing: Selective reception and multiple feeding, load balancing per packet.
  • MultiCast: IGMPv1, IGMPv2, IGMPv3, PIM SM, PIM DM, MSDP, MBGP, IPv6 PIM, and MLD.
  • IPv4 routing policy, static route, RIP, OSPF, IS-IS and BGP
  • IPv6: static route, routing policy, RIPng, OSPFv3, IS-ISv6 and BGP4+.

Electrical and Physical Specifications

  • Dimensions (Height, width and length): 44.4 mm x 442.0 mm x 220.4 mm.
  • Weight: 3.2kg.
  • Power supply: 100 V AC to 240 V AC, 50/60 Hz.
  • Maximum electrical consumption 33W.
  • Operating temperature: 0°C to 45°C.

  • Package content

  • 1 AR720.
  • Installation Manual.
  • AC electrical cable.
