Box Type Camera Cabinet (Professional) / For High Temperatures (up to 250º C) / Water Cooling System

  • c27d01412d6b976f2fb8277a3831c800
  • 40f286104004ba6ba2d6898309b0dcd3
  • 0164f464d48261465c8c1999d18df829
  • 57bb08f994912d5ce723ddbd4eef7501
  • 30f442a8f1ce4f7159be09efecb7dfeb
1 5
  • Capa dual acero inoxidable resistente a corrosión
  • Protección IP68 para uso exterior extremo
  • Operación segura de 0 a 250°C
  • Dimensiones internas 100 mm diámetro, 280 mm largo
  • Vidrio frontal 65 mm para visualización clara

Out of stock

Modelo: SHL-7013-04

Proveedor: SYSCOM VIDEO

Código SAT: 46171509

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Applicable in industrial processes (Steel, Cement, Electricity, etc.).

Cabinet Features.
-Made of dual layer stainless steel.
-Supports IP68 for outdoors.
-Semi-fixed bracket and 2 hoses included.
-2 Entries of 10 mm diameter for wiring.
-G1/4" water inlet/outlet valves.
-Diameter of the front glass of 65 mm.
-External dimensions 300 x 134 x 151mm.
-Internal dimensions Diameter 100 mm, Length 280 mm.
-Operation temperature 0º to 250ºC. Weight 4 kg.
-Power included 110 Vac. at 12 Vdc for camera.

Requirements for the Cooling system (Not included)
-Atmospheric Pressure 86 Kpa -106 Kpa.
-Dust concentration less than 200 mg/m3 (cement dust as base).
-Water temperature less than 35ºC.
-Water flow from 0.3L/s to 0.6L/s.
-Hydraulic Pressure of 0.1 Mpa.
-Shielded high temperature cable (Power 2 x 1.0 mm2, data 2 x 0.75 mm2, Video 75 ohms).

*1 year warranty.
