Professional Power Supply / 4 Outputs / 11-15 Vdc / 6 Ampere / Supports Backup Battery (Not Included) / Input Voltage: 100 - 240 Vac

  • ed6291ed15b5869f897e819daa5260e9
  • 562f432041b5b5375f0af398e28100f5
  • f6cf36389cde3dc0d6f0b58e381579c8
1 3

Out of stock

Modelo: XP15DC6BK

Proveedor: EPCOM POWERLINE

Código SAT: 39121009

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

XP15DC6BK

11-15 Vdc / 6 A supply

Energy efficiency, with overvoltage protection , short circuits, anti-interference protection circuits

The green light turns on, when the source has its 100-240 Vac power input, thus supplying both the battery charge and the required charge. When the power fails, the battery provides the voltage, the red led turns on, and at the same time enters the battery voltage monitoring stage, when it detects that the battery voltage drops to 10.5 Volts, the circuit will cut off the load, the power supply will no longer charge, to prevent the battery from discharging, thus protecting the life of the battery, The system will reboot automatically when the mains power returns, to its normal state.

Characteristics

  • Output voltage: 11-15 Vdc
  • Total current output: 6 A
  • Maximum current output per channel: 1.5A
  • Backup battery capacity at 12 Vdc
  • Battery is not included

Physical and Electrical Characteristics

  • Input voltage: 100-240 Vac
  • Operating temperature: -20°C to 45°C
  • Dimensions: 380mm*250mm*80mm (L*W*H)
  • Warranty: 1 year.

Related Models:

  • On CCTV (4.5 -9.5 Ah):
  • PS12DC4PBK.
  • PLK12DC8ABK.
  • PLK12DC4ABK.
  • PLK12DC20ABK.
  • PLK12DC16ABK
  • P13DC3BK
  • P13DC5BK
  • In Access Control (4.5 - 9.5 Ah):
  • PL12DC3ABK
  • PL12DC5ABK
  • In CCTV / AC (4.5 - 18 Ah):
  • XP15DC6BK
  • XP15DC10BK
  • XP15DC30BK
  • Battery cabinet requirement:
  • P24350BK
  • PSR30A
