ePMP 3000 MU-MIMO 4X4 802.11ac Base Station, 4910-5970 MHz, 120 Subscribers, Up to 1.2 Gbps (C050910A101A)

  • 86c09373f8273fae09e03eeeb764923f
  • cdda03331188ec789aea816a218df456
  • a88dc5e0ea135369e349c50bf098e9e2
  • 045023236b2285f0ddac779e672d695d
  • e44d20f6f776b54616d65978d7e9ed76
1 5
  • GPS synchronization for reuse of frequencies in the same tower
  • Beam steering: technology to focus the signal towards its objectives
  • Dynamic filter: Blocks noise from signals outside the network

Low stock: 2 left

Modelo: EPMP-3K

Proveedor: CAMBIUM NETWORKS

Código SAT: 43221709

Tax included.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details


802.11ac
WAVE 2 MU-MIMO
4x4 32
dBm PMP
Up to 1.2 Gbps

QUALITY OF SERVICE

A powerful multi-level prioritization scheme that can be configured by the network operator to enable the delivery of differentiated services.

SECURITY

128-bit AES encryption, L2 and L3 firewall rules, compatibility with different user levels, HTTP/SSH support provides enhanced security.

FLEXIBLE MODES OF OPERATION

Provides extremely low latency for PmP deployments, highly scalable mode with GPS synchronization and TDD operation for synchronized towers

NEW CHANNEL SIZE AND MODULATION

Supports channel size configuration from 20 MHz to 80 MHz and modulates up to 256 QAM

INTEGRATED LIVE SPECTRUM ANALYZER
Supports constant monitoring of the radio spectrum and allows live action without dropping the link.

MIMO and modulation MU-MIMO 4x4 / 256 QAM-5/6
Frequency range 4910 – 5980MHz (defined by country of operation)
Power Range 0 to +32 dBm (combined, depending on EIRP allowed in region)
Channel Width 20Ι40Ι80Mhz
Maximum power consumption 25W Maximum
Exterior protection / Temperature IP55 / -30º to +55ºC
Management HTTPs, SSH, SNMPv2c
Subscribers by Sector in PMP up to 120 clients
DSO Dynamic frequency optimization
Ethernet structure 10/100/1000BaseT, self-negotiation, 802.3at & SFP Auxiliary Port
Protocols used IPv4, UDP, TCP, IP, ICMP, SSH, SNMPv2c, HTTPs, STP, SSH, IGMP Snooping
VLAN 802.1Q with 802.1p priority
Input voltage 44 to 59V
Dimensions / Weight 22.2 x 12.4 x 4.5cm / .7kg
Antenna connector Antenna 4 x 50 ohm, SMA H Inverse
GPS GPS antenna included
Warranty 3 years

PoE included and electrical connection cable

Version up to 120 subscribers

Smart filter

Noise is always a concern, and as more transmitters are deployed, will continue to be
a critical factor in the operation. Although almost all radios have some type of filtering, many use
Static filters that block only noise from outside the radios' total operating spectrum. Yes ok
This provides a clear channel for operation, These systems with fixed filters still allow noise to
of neighboring channels affects system performance. Cambium Networks solutions use the
dynamic filtering with a static filter to block noise from outside the operating spectrum, but also
a dynamic filter to block interference from adjacent channels. As the system changes to
another channel, The system automatically blocks noise from adjacent channels to improve the quality of
the signal.

Frequency reuse

The frequency is limited. There will never be more of that. By reusing frequencies when deployed in a back-to-back configuration, a network operator can effectively use the same frequency twice to connect users. In large implementations, A network operator can connect thousands of users by reusing the same frequencies in the field service area. This technology maximizes the use of available frequency and can provide access to thousands of users on a small amount of spectrum.

GPS synchronization

When networks become denser, self-interference becomes a problem. GPS synchronization

coordinates the entire network, reduces self-interference and keeps network performance high as more

more subscribers.

Smart Beamforming and Beam Steering

As more emitters are deployed in the service area, It is important to mitigate noise and

interference to provide reliable high-speed connectivity. The access point

ePMP 3000 works in conjunction with the optional beam steering antenna to create narrow beams in

the uplink to improve the signal to noise ratio. Located at the access point of a tower,

The smart antenna will create tighter beams to connect with subscribers while overriding

radiation from unwanted emitters in the field.

Air Fairness

ePMP employs a sophisticated starvation avoidance algorithm based on priority and air fairness to allocate RF resources to SMs. Assignments are based on airtime rather than performance, so we avoid the situation where SMs in poor RF conditions consume an excessive amount of time and, therefore, available capacity.


cnMaestro

LINKPlanner

cnArcher

cnHeat

cnMaestro™ is an on-premise or cloud-based software platform for secure end-to-end network control. cnMaestro Wireless Network Manager simplifies device management by offering complete network visibility and touchless provisioning. View and perform a full set of wireless network management functions in real time. Optimize system availability, Maximize performance and meet the emerging needs of business and residential customers.

LINKPlanner allows you to model "what if" scenarios (based on geography, distance, antenna height, transmit power and other factors) to optimize system performance before purchase. Quickly design networks for optimal deployment and profitability with ease. Available for Microsoft® Windows® and Mac® systems, is a free and easy to use link design tool.

LINKPlanner leads the industry as the most reliable and intuitive RF link planning tool, with tens of thousands of links successfully deployed around the world.

Raise the bar on installation accuracy with cnArcher™, The free mobile app that provides field technicians with the information they need to properly configure and align Cambium Networks PMP and ePMP wireless broadband subscriber modules.

Built on Cambium Networks' experience in RF planning, propagation and modeling as seen in LINKPlanner and integrated with GIS data up to 1 meter accuracy, cnHeat generates highly accurate RF predictions and derived services that accurately represent the reality of the RF world.
