4-WAY REACTIVE DIVIDER 575-5925MHz 300W -161dBc 1.3-10 IP67

  • 33d44ef7a7449331c67ad1fcd6570df8
  • aa13effdb0aed5b0250a05bfac91a8c6
1 2

Out of stock

Modelo: D4-83FE

Proveedor: MICROLAB

Código SAT: 32101500

Tax included.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

4 WAY REACTIVE DIVIDER 575-5925MHZ 300W -161DBC 1.3-10 IP67

Description

Microlab Dx-83FE 2/3/4-Way Reactive Power Splitters have been designed to evenly split high-power cellular signals with minimal reflections or losses. All joints are sealed against moisture with O-rings to meet IP67 rating. The mechanical shape allows for easy wall mounting using the supplied brackets. The ultra-wide frequency range enables use in 5G NR deployments with multi-band antennas and leaky cable systems. With few solder joints and an air dielectric, loss has been minimized and reliability has been improved.

Characteristics

  • Ultra-wideband splitters for LTE-LAA
  • 300W average power
  • Guaranteed low PIM
  • Minimum RF Insertion Loss
  • IP67 rating
  • RoHS
  • 4.3-10 Flange Connectors

Specifications

Frequency: 617 – 5925MHz
Can: 300 W on average, 1 kW peak
Split loss: 6dB
VSWR: 1:30:1 max @617-3800MHz
1:35:1 max @4900-5925MHz
PIM: -165 dBc (-122 dBm) typical.
<-161 dBc (-118 dBm)
(test with 2 tones of +43 dBm)
Connector: 4.3-10 f)
Ingress Protection: IP67
Weight: 10 pounds (045 kg)
