Passive Motion Detector / Perimeter / Long range (100m x 3m) / Anti-masking and Anti-rotation Function

  • 0b70733e255268d36e3a72c89f214064
1 1

Out of stock

Modelo: RW-SIP-100

Proveedor: OPTEX

Código SAT: 39122236

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Product Details

The REDWALL SIP series includes long range outdoor PIR detectors designed to work in conjunction with CCTV systems to provide a reliable commercial security solution. Very stable in outdoor environments, Redwall SIP motion sensors combine a high capture rate with a minimal false alarm rate, which is ideal for event-triggered intrusion detection systems. The SIP-100 is a wired model that offers a detection rate of 100 x 3 m (L x W) which is ideal for protecting long, narrow areas such as fence lines, buildings or alleys.

Designed to activate CCTV systems Weather and vandal resistant
The REDWALL SIP series is designed to connect to PTZ or fixed cameras and activate the CCTV system when an intrusion occurs. The SIP-100/5030 has three independent detection zones (far, near and immediate) with independent sensitivity selection that can activate preset cameras and provide the best view of the scene to local security personnel or at remote monitoring stations. REDWALL SIP motion sensors are designed for use in demanding outdoor environments. Sensitivity can be automatically adjusted to ambient lighting and temperature, and have IP65 rating for the main unit. SIP long range intrusion detectors are vandal resistant as they have a polycarbonate housing and anti-masking function, in addition to having an accelerometer to detect whether or not the position of the sensor has been modified.

Applications

  • Buildings
  • Perimeter
  • Access

Characteristics

  • 100 x 3m Smart Outdoor PIR with Advanced Detection Algorithm
  • Designed to activate CCTV systems
  • 3 independent detection zones with 3 outputs (far/near/immediate)
  • Active infrared anti-masking and vandal resistance


**AVF-1 and AWT-3 tools required for proper installation**

Power input:
11 - 16VDC, 22 - 26 VAC (22 - 26VAC with optional heating unit)
Alarm output:
NO, NC 28VDC 0.2A max
Current consumption:
45mA max at 12V DC, 80mA max at 24 VAC (420 mA max (24 VAC) with optional heating unit)
Operating temperature:
-13° to +140°F (-40° to +140°F with optional SIP-HU heating unit)
Detection images:
Coverage: 330' x 10' top smart PIR detector with anti masking and rotation
