Designed for Hazardous Locations

• For simple doors that open outwards, with side mounting.
• Low header projections. This will accommodate most door conditions without the need for a filler plate or special support.
• Low energy consumption; 0:26 amps at 24 VDC
• 0:50 amps at 12 VDC. 24 V DC supplied as standard
• 1200 lbs. holding force.
• Door Position Switch (DPS) standard feature.
• Built-in surge protection.
• Without pins, latches or moving parts to prevent failures that could prevent safe egress in an emergency situation.
• Satin anodized aluminum finish.
• Door Brackets for Hazardous Locations:
• Category – FDGF. Complies with class I, division 2.
• Tested to UL228 - door closer brackets with/without integral smoke detectors.
