OptiCom® Multimode Fiber Optic Cassette OM4, With MPO to 6 LC Duplex Connector, Method A Polarity, Standard Insertion Loss

  • a6d09016db5d05382b1d2a19fd552468
  • 43119937571198cf38e56d9cf8584a10
  • b1333312fd723bd173c435296a98af62
  • 67aab58d4f100f40bb2557457c4fba1b
1 4
  • Adaptadores LC/SC preterminados para alta densidad
  • Pérdida de inserción máxima de 0.75 dB
  • Conector MPO macho con mínimo retorno 26 dB
  • Compatibilidad con fibras multimodo y monomodo
  • Cumple con estándar TIA/EIA-568-C.3

Low stock: 5 left

Modelo: FC2ZN-12-10AS

Proveedor: PANDUIT

Código SAT: 43223310

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

QuickNet™ MTP* fiber optic cassettes consist of pre-terminated LC or SC adapters for quick and easy deployment in high-density applications and provide efficient use of cabinet space and design flexibility. They meet all multimode and singlemode channel requirements. QuickNet™ MTP* fiber optic cassettes are available with a standard channel insertion loss of 0.75 dB maximum and an optimized loss of 0.5 dB maximum.

  • OM4 fiber type
  • Number of fibers: 12
  • Connector 1: LC Duplex
  • Material: Ceramic Zirconia
  • Adapter: Aqua Color
  • Connector 2: MPO Male
  • Maximum connector insertion loss (dB): 0.75
  • Minimum connector return loss (dB): 26
  • Overall Width (in.): 3.5
  • Total width (mm): 89
  • Overall Depth (in.): 4.2
  • Total depth (mm): 106
  • Overall Height (in.): 1.4
  • Total height (mm): 35
  • Standards Compliance: Meets or exceeds the performance requirements of TIA/EIA-568-C.3. Supports IEEE 802.3ae and ANSI T11.2 (Fibre Channel) link and channel specifications. Complies with ROHS 2002/95/EC.
  • Aqua color
  • Fiber diameter (µm): 50
