Reelex UTP Cable Reel, 4 Pairs, Cat6 Performance, PVC (CM), Gray Color, 24 AWG, 305m

  • 56d83804c93a61b3f660bf0da8863ab8
  • 56d83804c93a61b3f660bf0da8863ab8
1 2
  • REELEX® type coil design for easy pulling and installation (knot-free)
  • High performance, complying with TIA/EIA and ISO/IEC standards
  • Low loss 24 gauge solid copper conductor
  • Certified up to 100 meters and 250 MHz
  • Bending radius: 25mm

158 in stock

Modelo: 9C6M4-E2-RXA

Proveedor: SIEMON

Código SAT: 26121609

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details


The Siemon cable solution 6, Meets all ANSI/TIA and ISO/IEC Category 6/Class E transmission performance specifications. Combining high-performance Cat6 connectivity with the 6 cable solution gives us a result designed for optimal support applications.

It has a central isolation (Cross) which maintains the geometry of the isolated pairs for optimal "NEXT" performance.

Applications:

  • High Speed ​​Voice/Data and Video Networks
  • IP Megapixel CCTV Installations
  • Wireless networks
  • Power Over Ethernet IEEE 802.3af and 802.3at Applications
  • Applications in 10BASE-T, 100BASE-T, 1000BASE-T

Technical information:

  • Performance: Certified up to 100 meters
  • Gray
  • Conductor: 24 AWG solid copper
  • Coating: PVC (CM)
  • Construction: UTP
  • Maximum tension: 80 N
  • Temperature rating: 5 to 60°C in installation. 0 to 60°C in storage and -10 to 60°C in operation.
  • Frequency: 250MHz
  • Recommended Plug: P6U-8-8
  • Plug Tool: PA1561
