Intrinsic barrier for explosive risk applications

  • 80d13b2e4cc82c42b2c45f0475c780a6
1 1
  • Detectores tri-metálicos con resistencia extremadamente baja
  • Polímeros avanzados descomponen a temperaturas específicas
  • Protección NEMA 4 (IP66) contra fuego
  • Tensión nominal de 24VDC a 28VDC
  • Corriente nominal máxima: 100 mA

Out of stock

Modelo: RG-5224

Proveedor: SAFE FIRE DETECTION INC.

Código SAT: 46171600

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Description
SafeCable Linear Heat Detection (LHD) uses advanced polymers and a newly developed alloy to provide exceptional detection, durability and design flexibility. At the core of SafeCable is a twisted pair of extremely low resistance tri-metallic conductors, which are jacketed with new, advanced thermal polymers. These polymers are chemically engineered to decompose at specific fixed temperatures, allowing the stranded conductors to make contact and initiate an alarm.

  • Fire Resistant
  • NEMA 4 (Ip66)
  • Includes BIS and DIN rail
  • Ready to Use
  • For explosive hazard applications
  • 1 per zone
  • Current Limiting: Resistive
  • Nominal Voltage: 24VDC - 28VDC max.
  • Nominal Current: 100 mA max.
  • Leakage Current: 1µA unless otherwise stated
  • Rating Replacement fuse 160mA per channel
  • Mounting Location: Non-Hazardous or Class 1 Div.
  • Temperature Effect: <0.25% / 10K
  • Short Circuit Proof: Yes, unless otherwise stated
  • Frequency Range: 100 KHz @ >50 mA
  • Grounding Method: By Mounting Platform
  • Temp. Operating Temperature: -4°to+140°F(-20°Cto60°C)
  • Mounting Enclosure: 35mm DIN Rail in HDJ/ELR Case
  • Humidity Range: to 95% non-condensing
  • Dimensiones (W x H x D): 4 5/8 x 4 1/8 x 4 5/8” (11.75 x 10.48 x11.75cm)
  • Weight: 1.07 lbs (.49 kg)
