NPPROS Antenna Waveguide Adapter Support Connected Radios

  • a0b329cdf491175dae01c27f463201b9
  • e30fd2c514977efa208f6f79b6bfc665
  • f6fda846052e41799627607c7949e86f
1 3
  • Antena parabólica de 42 cm con 27 dBi de ganancia
  • Rango de frecuencia 4.9-6.4 GHz, el más amplio
  • Conectividad para radios C5C, B5C, RP5ACGen2
  • Montaje robusto, resistente a 120 km/hr de viento
  • Certificado de calibración CENAM incluido

Out of stock

Modelo: TWNP

Proveedor: NetPoint

Código SAT: 43222600

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details



Directional Antenna of 42 cm Diameter, 4.9-6.4 GHz 27 dBi, for Point to Point applications.

Differentiators:
The widest frequency range on the market.
Connectivity for C5C radios, B5C, RP5ACGEN2, EMPM Etc.
Highly robust and stable assembly.
Calibration certificate from CENAM (National Metrology Center).

Electric specifications :
Frequency Range: - GHz 4.9 - 6.4 GHz
Antenna Type: Parabolic
Connector Type: Twins Waves
Gain 27 dBi
VSWR: < 2.0 / 9.54
HPOL beam width: 8.2°
VPOL beam width: 8°
Voltage: 20 Kws
F/B Radio: >25 dB
Impedance: 50 ohm

Mechanical Specifications:
Wind resistance speed: 120 km/hr
Azimuth Adjustment: 360°
Elevation Adjustment: ±15°
Suggested mast diameter: 50 - 70, 100 - 114mm
Operating Temperature: -45 to +60℃
Gross Weight: 4.5 kg
Net Weight: 3.55 kg
