Hybrid Coupler for 2 Channels, 406-512 MHz, 125 Watt Load, N Females.

  • 77509691e13ddf4973af7841d1ffa4be
1 1

Out of stock

Modelo: 2550/5A

Proveedor: EMR CORPORATION

Código SAT: 32121800

Tax included. Shipping calculated at checkout.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

Hybrid Coupler for 2 Channels, 406-512 MHz, 125 Watt load, N Females.

Electric specifications

  • Description: Hybrid Coupler .
  • Maker: EMR Corporation
  • Part Number: 2550/5A
  • Frequency Range: 406 - 512 MHz (450-465 MHz)
  • Input Power (Per Port): 125 Watt.
  • Bandwidth: 35 MHz.
  • Insertion Loss: 3.2 dB.
  • Port to Port Isolation: 25+ dB.
  • Impedance: 50 Ohm.
  • VSWR (Max.): 1.5 :1
  • Temperature Range : - 22 to +140 °F
  • Panel D immensions: 3 1/2 x 19 in.
  • Connectors (Input / Output): N Female / N Female.
  • Finish: EMR Gray.
  • Shipping Weight: 4 kg.

*Ask for availability.
