Audio Booster Amplifier | 1 channel | 500w | Class D | Output 100V / 4-16Ω | Rack mounting | RCA

  • 137d9d258301bc9cf97b818850d2a137
  • 4385832799db14c33fce08d0ec8de10e
  • 330e3ea5eed160f42bb8522ed0e4410d
1 3

Low stock: 2 left

Modelo: EP1500DSV2

Proveedor: EPCOM PROAUDIO

Código SAT: 45111706

Tax included.
Our Commitment ×
By purchasing this product you are making a positive impact. We contribute of each sale and we’ve partnered with WeAreGoodness.io
Let’s do some good
View full details

General characteristics

  • High efficiency Class D digital amplifier
  • 1 output channel
  • 1 balanced input channel (terminal block)
  • 1 RCA
  • Front control
  • Signal peak indicator: short circuit and overload
  • Overheat protection
Audio Feature
  • Speaker output: 100V / 4-16Ω
  • Input sensitivity: ±385mV / 20KΩ, balanced input
  • Frequency response: 80Hz -16KHz (-3db)
  • THD: ≤0:1% at 1KHz

Physical and electrical characteristics

  • Rated output power: 500W
  • Input power: 110VAC 50/60 Hz
  • Power consumption: 650W
  • Dimension: 484 x 44 x 315mm
  • Overheat protection, short circuits and overload
  • Weight: 3.9 Kg.

Note:

*It is necessary to use voltage regulators when installing the amplifier if the outlet is greater than 127Vac.

* Recommendation for use : Do not connect more than 80% of the load to the amplifier, for example, if the power of the amplifier is 500W, only connect a maximum of 400W (20% safety).

500w booster amplifier
The EP1500DS amplifier provides excellent signal quality with the highest efficiency. It has short circuit protection, over load and high temperature.
It can be used in different places to meet the needs of paging and background music.
Ideal for growing audio systems to place 100V (High Impedance) or 4 - 16 Ω speakers
